Mastodon™ Engineered Frame System

  • The Mastodon™ batting cage frame system includes 8.625" outside diameter structural steel pipes coated with the same finish used on the Alaska Pipeline.
  • It has fewer components, and offers free and clear spans up to 75' in either direction - without significant sag.
  • The poles come completely prepared to accept our tensioning hardware and the following is included: structural steel poles, heavy duty 3/16" galvanized aircraft cable (enough for a 14' x 80' footprint), galvanized steel carabiners.
  • A cable tensioning system ensures that your net will hang properly and needs no special tools.

Sizes

Extended Size Double Stall

Double Stall 12'H x 14'W x 80'D
Double Stall 14'H x 14'W x 55'D
Double Stall 14'H x 14'W x 70'D
Double Stall 14'H x 14'W x 80'D

Double Stall Mastodon™ Batting Cage
Double Stall 12'H x 12'W x 55'D
Double Stall 12'H x 14'W x 55'D
Double Stall 12'H x 12'W x 70'D
Double Stall 12'H x 14'W x 70'D

Extended Size Single Stall
12'H x 14'W x 80'D
14'H x 14'W x 55'D
14'H x 14'W x 70'D
14'H x 14'W x 80'D

Mastodon(TM) Batting Cages

Bear Trap Net

  • #62 knotless KVX200™ netting
  • Corner loops for easy installation.
  • Top center rib line. (height control)
  • 6' tails each upper corner
  • Posi-lock stitched rope borders.
  • Free 5'x7' HD Vinyl Backdrop
  • Free KVX200™ ball cap

Cable Tensioning System

  • Our cable tensioning system uses galvanized hardware including 3/16" aircraft cable, cable clamps, thimble eye nuts, eye bolts, institutional grade threaded rod, and curved washers.
  • In order to achieve the proper cable tension, the poles in the system shown have 11.5' exposed, and approximately 4.5' in the ground.
  • There are some custom options available, such as larger diameter cable (for larger structures) - call for more information and additional pricing.

Upgrade your baseball or softball field by adding batting cages.  Van's Enterprises can provide the right cage to fit in with your field layout.

Single Stall Mastodon™ Cage
Frame without Bear Trap
12'H x 12'W x 55'D
12'H x 14'W x 55'D
12'H x 12'W x70'D
12'H x 14'W x 70'D

Corrosion Resistant Coating

  • All poles are corrosion dipped, finished with STRYK 5388, and sealed with a welded top cap preventing internal corrosion. STRYK 5388 forms a solid coating which bonds to the substrate, preventing corrosion even if coating is scratched or damaged.
  • STRYK 5388 is a thick rust-inhibitive coating used on the Alaska pipeline with a high degree of impermeability to moisture.
  • The finish remains highly flexible and elastic in extreme temperatures.
  • It will not support fungal growth in humid or water-immersed environments or crack in extreme weather conditions.
